Which Ground Protection Mats Right For You?
LITE
O.G.
Heavy Duty
Model Size
4'W X 8'L X .375"H
4’W x 8’L x .5’’H
13.1 ft x 6.5 ft
Total Thickness
.375" MAT + .375" CLEAT
.5” mat + .375” cleat
4 inch | Core: 3.7 | Overlap: 7.8 inch
Area Coverage
4 FT X 8 FT = 32 SQ FT
4 FT X 8 FT = 32 SQ FT
5.9 ft x 12.50 ft = 3.75 sq ft
Weight
61 LBS
81 lbs
793 lbs
Colors*
*Custom colors subject to a minimum order quantity
Operating Temperature Range
UL 94 HB
UL 94 HB
UL 94 HB
Environmental
Does not absorb liquid or chemicals, easy to clean, allows easy decontamination cleaning
Does not absorb liquid or chemicals, easy to clean, allows easy decontamination cleaning
Does not absorb liquid or chemicals, easy to clean, allows easy decontamination cleaning
Compressive Load Capacity
-
-
605 psi without deformation or breakage
AST Additive
-
-
Tested according to DIN standard IEC EN 62631-3-2:2016
RFID or GPS Tags
-
-
Option to install your tag of choice within weatherproof pocket
Load Bearing Capacity
-
-
In excess of 200t*
Withstands (tonnage)
Up to 60 tons
Up to 90 tons
Up to 730 tons
Connection System
MATS CONNECT USING 2-WAY OR 4-WAY METAL CONNECTORS
Mats connect using 2-way or 4-way metal connectors
Fast Four3 connector pin system
Shipping
U.S standard flatbed truck: 54 mats per standard flatbed truck
40 foot HC container 52 mats
U.S. standard 48 ft. flatbed truck: 510 mats
U.S standard flatbed truck: 54 mats per standard flatbed truck
U.S. standard 48 ft. flatbed truck: 510 mats
40 ft. ISO shipping container: 500 mats
20 ft. ISO shipping container: 230 mats
U.K. lorry/EU trucks: up to 600 mats
